M40 M25
TURBO M40 M25 Springs Pulse Jet Valve FP40 FM40 DP40 DM40 SQP40 Diaphragm Kit
FEATURES
1. The pulse diaphragm valves are especially designed for dust collector service applications, combining high flow, long life and extremely fast opening and closing to produce reliable and economical operation
2. The high flow, angle type bodies in combination with the special main diaphragm assemblies give the unique operating features required for dust collector service applications
3. The design with integral compression fittings will facilitate installation because there is no need for threaded piping
4. The high quality diaphragms are reinforced and wear resistant to guarantee a long operating life, even under harsh conditions
5. Integral pilot operated valves satisfy all relevant EC directives
GENERAL
Differential pressure: 0,15 - 8,5 bar [1 bar = 100kPa]
Ambient temperature range: -20 to +85°C
MATERIALS IN CONTACT WITH FLUID
Note: Ensure that the compatibility of the fluids in contact with the materials is verified
Body: Aluminium
Core tube: Stainless steel
Core and plugnut: Stainless steel
Springs: Stainless steel
Seals & disc: NBR (nitrile)
Diaphragms: CR (chloroprene)
Shading coil: Copper
